E-motor

VRMH110.500DC

Core Data
Position Rear Motor
Wheel Diameter(Inch) 20″-28″
Construction Gear drive
Rated Voltage(VDC) 36/48
Rated Power(W) 350/500
Maximum torque(N.m) ≥58/65
Efficiency(%) ≥80
Weigh(kg) 3.5
Noise Grade(dB) <55
Operating Temperature -20℃-45℃
Color Black/Silver
Mounting Parameters
Brake Type V Brake/ Disc Brake
Cabling Route shaft side left
Spoke Specification 36H*12G
Tests & Certifications
IP Test IP65
Certifications ROHS/CE
Salt Spray Test Standard(h) 96
